12. REAR WHEEL/BRAKE/SUSPENSION K-PIPE 50 50 Dust Seal DISASSEMBLY Remove the side collar and dust seal from the left side of the rear wheel. First tap the safety piece flat and then remove the four drive chain gear lock nuts. Remove the safety piece and drive chain gear. Remove the snap ring and gear gasket. Check the damping bushings for damage. Collar RR dist Lock Nuts Collar RR dist Remove the Collar RR dist. Drive out the wheel bearings and remove the distance collar. Bearing Remover ASSEMBLY Pack all bearing cavities with grease. Drive in the left bearing. Install the distance collar. Drive in the right bearing. Drive in the bearings squarely. Install the bearings with the sealed end facing out. Bearing Outer Driver 12-6
