          1. GENERAL INFORMATION   AGILITY CITY 50




                                    Fuel Tube




                                Auto Cock Assy Fuel

                                    Fuel Filter




  Throttle Cable




                                     Carburetor
                                     Overflow Tube

                                    Crankcase Breather
                                    Tube




   Ignition Coil
   Primary Wire




1-18
