2. EXHAUST MUFFLER/FRAME COVERS PEOPLE 250
RIGHT/LEFT SIDE COVER REMOVAL
Remove the screw combine right (left) side
cover with front under cover.
Remove the screw combine right (left) side
cover with the floor board.
Remove the right (left) side cover.
Screws
MET-IN BOX AND REAR CARRIER Bolts
REMOVAL
Open the seat with key.
Remove two bolts and two nuts on the met-in
box.
Disconnect all of the wire couplers.
Remove met-in box.
Remove three bolts and remove the rear
carrier.
Nuts Wire Couplers Bolts
BODY COVER/CENTER COVER/REAR
FENDER A REMOVAL
Remove six screws on air cleaner cover.
Screws
Loosen band to remove air cleaner cover and
disconnect air duct hose.
Band Air Duct Hose
2-6
