          12. FRONT WHEEL/FRONT BRAKE/
     FRONT SUSPENSION                                          PEOPLE 125/150

 Remove the top cone race.                                Top Cone Race


    · Be careful not to lose the steel balls (26
      on top race and 19 on bottom race).
    · Clean the openings of frame covers
      with clean shop towels.

 Remove the front fork.




 BOTTOM CONE RACE REPLACEMENT
 Remove the bottom cone race using a chisel.

    Be careful not to damage the steering
    stem and front fork.

 Drive a new bottom cone race into place with
 a proper driver.



                                                      Bottom Cone Race
                                                    Ball Race Remover

 BALL RACE REPLACEMENT
 Drive out the top and bottom ball races.




                                                   Outer Driver, 37x40mm
 Drive new top and bottom ball races into the
 steering head using the outer driver.
 Special
 Outer Driver 37x40mm




                                                                           12-16
