          3. INSPECTION/ADJUSTMENT                                        MXU 550EXi/MXU500i





   The threads on both rod-end must be of
   same length.




 WHEELS/TIRES
 Check the tires for cuts, imbedded nails or
 other damages.
 Check the tire pressure.
 Tire    pressure should be checked when
   tires are cold.

 TIRE PRESSURE
                           1 Rider
 Front         0.35 kgf/cm (35 Kpa, 5.0psi)
 (off road)
 Rear          0.32 kgf/cm (32 Kpa, 4.5psi)
 (off road)
 Front         0.38 kgf/cm (38 Kpa, 5.5psi)
 (on road)                                     Front Axle Nut

 Rear          0.35 kgf/cm (35 Kpa, 5.0psi)
 (on road)


 TIRE SIZE
   Front          : 25X8-12
   Rear           : 25X10-12--OFF ROAD
    Front         : 26X8-14
    Rear           : 26X10-14--ON ROAD


 Check the front axle nut for looseness.

                                                                            3-24
