3. INSPECTION/ADJUSTMENT MXU 550EXi/MXU500i
ENGINE OIL REPLACEMENT (WITH
OR WITHOUT OIL FILTER
CARTRIDGE REPLACEMENT)
1. Place the machine on a level place.
2. Warm up the engine for several minutes
and stop it.
3. Place a container under the engine.
4. Remove the oil fill cap (1).
Be sure no foreign material enters the
crankcase.
5. Remove the drain plug (2) to drain the
oil.
The engine oil will drain more easily
while the engine is warm.
Skip steps 6 to 10 if the oil filter
cartridge is not being replaced.
6. Remove the three fasteners (3) and then
remove right side cover (4).
3-14
