          3. INSPECTION/ADJUSTMENT                       MXU 550EXi/MXU500i



 Measure the spark plug gap between the
 center and side electrodes with the feeler
 gauge.
 If necessary, adjust the gap by bending the
 side electrode carefully.
 Spark plug gap:
             0.60.7 mm (0.0240.028 in)
 Install the spark plug in the cylinder head
 and hand tighten, then torque to the
 specification.
 Torque: 1.2 kgf-m (12 N-m)Install the
 spark plug cap.
 Install the removed parts in the reverse
 order of removal.
