16. BRAKE SYSTEM                                              MXU 550EXi/MXU 500i


                                                Dust Boot          Drive Bolt
Inspect the dust boot for deterioration or
damage.
If any damage is found, replace it with a new
one.

Remove the drive bolt and dust boot.




                                                Brake Shaft              Shaft Guide
Inspect the drive shaft and shaft guide for
wear or damage.




                                                                Parking Brake Case

Remove the two bolts and parking brake case.




                                                                                16-42
