13. DRIVE TRAIN MXU 500IRS
FRONT ASSY GEARCASE
REMOVAL/INSPECTION/
INSTALLATION
REMOVAL
Drain the front assy gear case oil (refer to
the "FRONT DRIVE GEAR OIL" in the
chapter 3).
Remove the steering knuckle (refer to the
"STEERING KNUCKLE
REMOVAL/INSPECTION/
INSTALLATION" section in the chapter
14).
Remove the front upper arms and front
lower arms (refer to the "FRONT ARMS
INSPECTION/REMOVAL/
INSTALLATION" section in the chapter
14).
Remove the drive shafts (refer to the
"FRONT DRIVE SHAFT
REOMVAL/INSPECTION/
INSTALLATION" section in this
chapter).
Disconnect the following wire connectors
.
13-11
