          7. ENGINE REMOVAL/INSTALLATION                    MXU 500 IRS

 Apply lightweight lithium-soap base grease
 to the front propeller shaft splines and front
 output splines.




 Install the front propeller shaft into the
 engine assembly.




 Always install the bolts with the new
   ones.




 Install the front cooling duct.

 Make sure the lug on the left crankshaft
   case into the cutout on the front cooling
   duct.
