18. STARTING SYSTEM MXU 250R/300R
Rubber Jacket Bolts
STARTER MOTOR
REMOVAL
Before removing the starter motor, turn
the ignition switch OFF and remove the
battery ground. Then, turn on the
ignition switch and push the starter
button to see if the starter motor
operates properly.
Remove the waterproof rubber jacket and
remove nut to disconnect the starter motor Nut
cable connector.
Remove the two starter motor mounting
bolts and the motor.
DISASSEMBLY Front Cover Motor Case
Remove the two starter motor case screws,
front cover, motor case and other parts.
Case Screws
INSPECTION
Inspect the removed parts for wear, damage
or discoloration and replace if necessary.
Clean the commutator if there is metal
powder between the segments.
18-3
