14. BATTERY/CHARGING SYSTEM/
A.C. GENERATOR Mongoose/KXR 90/50
CHARGING
Connect the charger positive (+) cable to the
battery positive (+) terminal. Red
Connect the charger negative (-) cable to the Power Lamp (Red)
battery negative (-) terminal. Charging Lamp
Black (Green)
· Keep flames and sparks away from a
charging battery.
· Turn power ON/OFF at the charger, not
at the battery terminals to prevent
sparks near the battery to avoid
explosion.
· Charge the battery according to the
ifi d h b
· Quick charging should only be done in
an emergency.
· Measure the voltage 30 minutes after
the battery is charged.
Charging current: Standard : 0.4A
Quick : 4.0A
Charging time : Standard : 510 hours
Quick : 30 minutes
After charging: Open circuit voltage: 12.8V min.
14-5
