          12. COOLING SYSTEM                                           K-XCT 125i
 THERMOSTAT
 THERMOSTAT REMOVAL

 REMOVAL

 Drain the coolant
 Remove the luggage box




                                               (1)   Bolts

 Disconnect the water hose (1) from the
 thermostat housing.


 Remove the mounting bolt (2) and the
 thermostat housing attaching the cylinder
 head.


 INSTALLATION

 The installation sequence is the reverse of
 removal.




 After the water thermostat has been
 installed, fill coolant and perform air
 bleeding .




                                                             12-18
