          6. CYLINDER HEAD/VALVES                          K-XCT 125i



 CYLINDER HEAD COVER

 REMOVAL

 Remove four bolts then remove the cylinder
 head cover.




 INSTALLATION

 Install a new cylinder head cover O-ring and
 install the cylinder head cover.
 Be sure to install the O-ring into the
    groove properly.




 Install and tighten the cylinder head cover
 bolts to the specified torque in a crisscross
 pattern.

 Torque: 0.8~0.9kgf-m




                                                     6-4
