          3. INSPECTION/ADJUSTMENT                             K-XCT 125i

FUEL LINE

Check the fuel lines and replace any parts which
show signs of deterioration, damage or leakage.




THROTTLE OPERATION
Check the throttle grip for smooth movement.
Measure the throttle grip free play.

Free Play: 26 mm




Major adjustment of the throttle grip free play is
made with the adjusting nut at the throttle body
side. Adjust by loosening the lock nut and
turning the adjusting nut.




                                                        3-4
