3. INSPECTION/ADJUSTMENT K-XCT 125i
1. Remove the oil filler cap/dipstick(1)
from the right crankcase cover.
2. Place a container under the left crankcase.
3. Remove the oil drain plug (2) to drain the
oil.
4. Reinstall the drain plug and tighten the
drain plug to specification.
Oil drain plug torque:
25 N-m (2.5 kgf-m,)
5. Fill the crankcase with the recommended
grade oil and install the oil filler cap.
Oil capacity (after draining):
1.0 L(0.95 US qt, 0.8 lmp qt) (1)
6. Start the engine and let it idle for 23
minutes.
7. Stop the engine and check that the oil level
is at the upper level mark on the oil filler
cap/dipstick with the scooter upright on
firm, level ground. Make sure there are no
oil leaks.
Let the engine and exhaust system cool
before working in those areas.
(2)
3-7
