          10. FINAL REDUCTION                                                          AGILITY 50
                                                   Resin Washer                   Countershaft
 Install the countershaft and gear into the left
 crankcase.
 Install the resin washer onto the countershaft.
 Install the dowel pins and a new gasket.




                                                   Gasket                        Dowel Pins

 Install the transmission case cover.




                                                                     Transmission Case Cover

 Install and tighten the transmission case cover
 bolts.
 Install the clutch/driven pulley. ( 9-13)




 After installation, fill the transmission case
 with the specified oil. ( 3-7)

    · Place the motorcycle on its main stand
      on level ground.
    · Check the oil sealing washer for wear                                      Bolt
      or damage.
 Specified Gear Oil: SAE90#
 Oil Capacity:
    At disassembly : 0.11 liter
    At change          : 0.10 liter
 Install and tighten the oil check bolt.
 Torque: 0.81.2kgf-m
 Start the engine and check for oil leaks.
 Check the oil level from the oil check bolt
 hole and add the specified oil to the proper
 level if the oil level is low.
                                                      Drain Bolt   Oil Check Bolt Hole/Oil Filler

10-5
